Shop
PhotosynQ technician inspecting a MultispeQ instrument for repair, firmware update, and recalibration diagnostic service

Repair, Firmware Update, and Recalibration Diagnostic

Send in one MultispeQ instrument for a full PhotosynQ 360 diagnostic inspection, firmware review, and recalibration assessment.

Our team will inspect your MultispeQ using our 360 diagnostics process and provide a report of any findings. The report will include recommended repairs, recalibration needs, and estimated costs if the instrument is outside the warranty period.

You stay fully informed before any additional work is completed. If repair labor, replacement parts, or recalibration services are needed, PhotosynQ will provide the recommended next steps and estimated cost for your approval.

This $75 service covers the initial diagnostic review. Return shipping, replacement parts, and additional labor may be billed separately if required.

Please allow at least 4 weeks for diagnostic review and service processing. Complex repairs may require additional time.
$75.00Price
Quantity

MultispeQ Features

Case

  • 5500 mAh internal battery, will last all day for typical use

  • Ergonomic design, right or left handed

  • Measure cuvette (algae) or leaf seamlessly

Sensors

  • Available LEDs and detectors for spectroscopy

    LEDs:
    448 nm, 530 nm, 590 nm, 655 nm (2x), 730 nm, 810 nm, 880 nm, 950 nm (2x)

    Detectors:
    400-700 nm, 700-1150 nm

  • Automatically adds location and time stamp to all measurements

  • Ambient temperature ± 0.5 °C

  • Contactless leaf temperature ± 0.1 °C in the 30 - 40 °C range

  • Relative humidity ± 3 %

  • Barometric pressure ± 0.25 %

  • Measure leaf angle (wilt) and cardinal direction

  • External sensor connector for ultimate modability

Usability

  • Automatic firmware updates through Mobile or Desktop App

  • Optimized power management to reduce overall power consumption

  • Collected measurements will be cached, allowing you to take measurements in remote locations.

  • Data can be easily viewed and analyzed in your browser.

  • Libraries for advanced analysis in R or Python are available.

Measurements

  • Measure fluorescence base parameters for plants and algae including ΦII, LEF, NPQ, qE, qI, qL, qPand absorbance based parameters like vH+, gH+, ECSt

  • Record abiotic factors including ambient temperature, relative humidity, barometric pressure and altitude as well as contactless leaf temperature, leaf angle and leaf direction

  • Flexible, system to create your own measurement protocols and code to analyse your data

  • Port for adding additional sensors (USB 3.0)

Specifications

DIMENSION


APPS

  • Android

  • Windows

  • Mac

CONNECTIONS

Micro-USB 2.0

Bluetooth

SOFTWARE

The instrument connects to the PhotosynQ network via mobile (Android) or desktop (PC or Mac) apps to collect measurements and save it to the online platform. There your measurements can be managed, analyzed, and shared with communities across the world.

Facts and Specifications

Development

  • Available LEDs and detectors for spectroscopy

    LEDs:
    448 nm, 530 nm, 590 nm, 655 nm (2x), 730 nm, 810 nm, 880 nm, 950 nm (2x)

    Detectors:
    400-700 nm, 700-1150 nm

  • Automatically adds location and time stamp to all measurements

  • Ambient temperature ± 0.5 °C

  • Contactless leaf temperature ± 0.1 °C in the 30 - 40 °C range

  • Relative humidity ± 3 %

  • Barometric pressure ± 0.25 %

  • Measure leaf angle (wilt) and cardinal direction

  • External sensor connector for ultimate modability

Experience

  • Automatic firmware updates through Mobile or Desktop App

  • Optimized power management to reduce overall power consumption

  • Collected measurements will be cached, allowing you to take measurements in remote locations.

  • Data can be easily viewed and analyzed in your browser.

  • Libraries for advanced analysis in R or Python are available.


Get a MultispeQ

and start today!
